Filterlogic FFL-111B Fridge Water Filter Compatible with CS52, 640565, 5586605 for Bosch, Siemens, Neff
Estimated delivery: Calculating…
Estimated delivery: Calculating…
Guaranteed Safe Checkout
Filterlogic FFL-111B Fridge Water Filter Compatible with CS52, 640565, 5586605 for Bosch, Siemens, Neff
Filterlogic FFL-111B Compatible CS52, 640565, 5586605, Bosch, Siemens, Neff Fridge Water Filter
The FilterLogic CS52 Fridge Water Filter reduces the following health related contaminants:
- Chlorine Taste and Odour
- Sediment
Tested and Certified by NSF International against NSF/ANSI Standards 42 for the reduction of Chlorine Taste and Odour. As with all built-in refrigerator water filters, the CS52 Fridge Water Filter does not remove Fluoride.
Note: The filter produces great-tasting and healthier drinking water and ice-cubes.
Important: Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. The contaminants or other substances removed or reduced by the water filter device are not necessarily in your water.
The CS52 Fridge Water Filter operating specifications are as follows:
- Flow Rate - 1.9 lpm
- Operating Temperature - min 4.4°C / max 37.8°C
- Operating Pressure - min 172 kPa (25 psi) / max 862 kPa (125 psi)
- Capacity - 5 678 litres
- Service Life - 12 months
- Dimensions - approximately 5.5 cm x 22.5 cm
Important: Do not install the water filter if the pressure is less than 172 kPa or greater than 862 kPa. If you are not sure what the water pressure is, contact an installation expert.
Change filter every 6 months.
Installation and replacement procedure for the CS52 Fridge Water Filter:
- Disconnect the refrigerator water supply and unplug the refrigerator.
- Press the knob at the top of the filter case and remove the cover from the compartment.
- Turn the filter 1/4 turn to the left (counter clockwise).
- Pull the filter straight out and discard.
- Remove the protective cap from the new water filter.
- Insert the new filter into the holder.
- Turn the filter 1/4 turn to the right (clockwise) to lock it into place.
- Replace the filter cover back into the compartment.
- Reconnect the refrigerator water supply and plug the refrigerator back in.
- Flush the new filter for 5 minutes to purge the system.
- Reset the "change filter" indicator light: Bosch / Siemens / Neff / Gaggenau fridges: Press and hold the Water Filter Reset button for 5 seconds. Newer models: Press theOptions button until the "filter change" function is selected, and then press selection button "+" or "-" until the "filter Change" display goes out.
When to change a filter: There is a replacement indicator message to change the filter cartridge on the digital panel. The water filter cartridge should be replaced when the "filter change" message appears, or every 6 months, or if you notice a decrease in flow of water.
Important: It is essential that operation, maintenance and filter replacement be carried out in accordance with manufacture's recommended procedures and guidelines for this product to perform as advertised. Failure to do so may void warranty.
| Brand/Manufacturer | FilterLogic |
| Contaminants Filtered | Chlorine Dissolved Organic Matter (DOM) Pesticides & Herbicides Sediment Volatile Organic Compounds (VOCs) |
| Product Name | Filterlogic FFL-111B Fridge Water Filter Compatible with CS52, 640565, 5586605 for Bosch, Siemens, Neff |
| Model Number | FFL-111B |
| Min. Working Temp. | 1°C / 33.8°F |
| Max. Working Temp. | 38°C / 100.4°F |
| Working Pressure | 2.07 Bar / 30 Psi / 207 kPa |
| Max. Working Pressure | 8.27 Bar / 120 Psi / 827 Kpa |
| Lifespan | 6 Months |
| Rated Capacity | 1135 Litres / 300 US Gallons |
| Weight | 0.275 kg |
